2219 T6 Aluminum Forging Parts Ultrasonic Tested Military Usage

Chongqing Huanyu Aluminum Material Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

2219 T6 Aluminum Forging Parts Ultrasonic Tested Military Usage

  • 1
  • 2

Brand Name : HUANYU

Model Number : HYFBL2219

Place of Origin : CHINA

MOQ : 1 METRIC TON

Payment Terms : T/T

Supply Ability : 20 METRIC TONS PER MONTH

Delivery Time : 3~4 WEEKS

Packaging Details : PLYWOOD CASE

Lead time : 3~4 WEEKS

Performance : High Strength And Excellent Fatigue Resistance

Application : Aircraft Structural Components

Surface treatment : Mill Finish

Contact Now

Ultrasonic Tested Military Usage 2219 T6 Aluminum Forging Parts

Technical Data Sheet

Aluminium Alloy 2219 is a high strength alloy which combines good machinability and good mechanical properties. 2219 is useful over a temperature range of -452°F to 600°F, is readily weldable and has good fracture toughness. In the T8 condition it is resistant to stress corrosion cracking.

Aluminium 2219 is typically used in a range of aerospace applications such as high temperature structural applications including space booster and fuel tanks.

Chemical Composition Limits
Weight%AlSiFeCuMnMgZnTiOthersVZn
Alloy 2219Bal0.20 max0.30 max5.80-6.800.20-0.400.02 max0.10 max0.02-0.100.050 each
0.15 total
0.05-0.150.10-0.25
Features:
Alloy temper: 2219 T6
Specification: L 800mm x W 600mm x 400mm
Introduction of mechanical properties:
Tensile strength: >410MPA
Yield strength: >330MPA
Elongation:> 8%
